Automotive

An innovative Automatic End of Line Cockpit Check Machine we have recently designed, developed and delivered for an Automotive corporate.

Download a PDF file for this project:
Automatic Quality Control Machine

For a well-known Automotive Brand we designed and developed a custom Vision System to check assembled components.

Download a PDF file for this project:
Vision System to check assembled components

For a well-known Automotive Brand we have created a series of 14 workstations with tracking management and quality controls, for the assembly and testing of the door panels of a well-known car model in the B segment.

Download a PDF file for this project:
Assembly and test workstation

Complete system of 10 shuttles for the handling of semi-finished products between the different production areas and assembly phases.

Download a PDF file for this project:
Complete AGV fleet system

R&D project for Industry 4.0 that integrates the connection between physical and digital systems with a complex Big Data analysis using the most advanced technologies: Web Supervisor and SmartGlass, MachineLearning and Conditional Monitoring applied to predictive maintenance, SensorWear and BigData for dyadic man - cobot).

Download a PDF file for this project:
4.0 machine to assemble/disassemble turbocompressors for petrol, diesel and electric engines.

Within an automotive seat production line, a fully automated real-time quality control system was introduced through a collaborative robot system equipped by sensors and cameras, with consequent zeroing of production waste.

Download a PDF file for this project:
Artificial vision system for real-time quality control by a collaborative robot

For a well-known multinational automotive company we have created a Traceability System for one production line that includes 9 processing stations (welding, tightness control, screwing, vision and pick to light).

Download a PDF file for this project:
Traceability System

In the Automotive sector we have created a LINE SUPERVISION SYSTEM that allows a real time production status on different devices (HMI, PC, Mobile).

Download a PDF file for this project:
Traceability System for production lines for Automotive

For an enterprise in the rubber segment, note we have designed and made a timing belts measurement machine. The machine, which consists of 2 axes, simulates the engine's performance, while laser sensors measure all the product characteristics, both dimensional (thickness, height and width of the toe and tooth height), as well as dynamics (derives from the belts on the pulleys and belt slackening). The added value of this system is its software, capable of assessing the angles of the rubber that normally points to signal acquisition problems due to the intrinsic characteristics of the rubber itself, as deformation and reflection.

Download a PDF file for this project:
Automotive 4.0 : timing belts measurement machine.

For an enterprise in Automotive area, we have designed and built an Industry 4.0 project, named “Collaborative Smartbench”: a series of assembling benches for the Porsche Cayenne interior panels. A step towards innovation is the use of a Universal Robots’ collaborative robot: thanks to its compactness and axle handling at almost 360° it is ideal for this application. This choice has allowed us to offer our customer higher quality and an effective reduction in security costs.

Download a PDF file for this project:
Collaborative “Smartbench”: Automotive Assembly Workstation

The project, called Smartbench, was carried out for a multinational leader in the automotive component sector. It consisted in the complete creation, for various European plants of the group, of semi-automatic door panel assembly benches, featuring assembly control and objectivation systems and supervision software on operator panel.

Download a PDF file for this project:
Smartbench: Automotive Assembly Workstation

The system, created for a multinational leader in the automotive component sector, consists of a complete automated welding line, using ultrasounds, for parts on panels made of plastic for automotive doors. The robots and structure for welding are equipped with ultrasonic sonotrodes.

Download a PDF file for this project:
Ultrasonic Welding Machine: Robotised ultrasonic welding system

In various plants of a leading multinational automotive component producer, Taiprora produced laser belt measurement benches and at the same time created software to manage the laser measurements integrated with the production management system.

Download a PDF file for this project:
Automotive belt laser measurement bench with measurement management software

The software intervenes, within the production process, immediately after the packing of the sleeves, assisting the operator in the procedure for assigning the sleeve in the container, and displaying the data expressed in graphs of temperatures and values inside the same containers during the vulcanisation process.

Download a PDF file for this project:
Rubber vulcanisation stage control and monitoring software

TaiP!Confezionatrice can provide effective assistance in controlling and managing the sleeves requested every day from the Production Operators. All activities will be monitored through a control network that puts the Operator’s work computer in communication both with the PLC of the packing machine and with the Company IT System, permitting constant availability of the detailed information not only of the belts and settings of the recipes to put into production, but also of the batches used, permitting complete traceability of all activities and all materials.

Download a PDF file for this project:
Software for monitoring the progress of production with control of the rubber sleeve packing machines

The project, carried out for a multinational leader in the automotive component sector, consisted of adapting the line for updated door panel model requirements, mainly by remaking the automation and control system and creating a new panel pallet locking system.

Download a PDF file for this project:
Revamping automotive door panel welding line

Maintenance management software permits management of system and machinery maintenance activity, organisation of routine and non-routine scheduled maintenance, up to urgent interventions due to an unexpected fault. The maintenance management software features standard and configurable reports (summary statistics tables) for assessing maintenance activity (each report can be printed onto paper or exported in Microsoft Excel format, for any further analysis by the user).

Download a PDF file for this project:
Industrial maintenance management software

Taiprora has created a production line control system for a multinational in the automotive/rubber sector. The main functions of the system are: - monitoring of the progress of production - data acquisition for quality control - management of traceability for finished products - anti-error management

Download a PDF file for this project:
Toothed belt production line supervision

The Client needed to be able to detect the dimensional characteristics of the fabric on the line and of the components applied to it, with the aim of: increasing the precision with which the finished product is made; reducing errors in position/width of the materials applied to the fabric; having a quality control tool that allows the production process to be guaranteed. 3D vision systems are understood as all tools capable of acquiring the spatial coordinates of a given region or of the surface of an object, automatically, systematically and at high speed. The basic principle on which the different types of laser are based is called “laser triangulation”.

Download a PDF file for this project:
Artificial three-dimensional vision and measurement of the characteristics of the rubberised fabric in tyre production

For a multinational in the automotive / aluminium die-casting sector, Taiprora has created an application to supervise the core-making department, storing in its database a lot of information on production and the working methods of the machine operators. The managers will thus have an effective tool that allows them to verify the efficiency of the machines, of the operators and, in general, the progress of productivity over time.

Download a PDF file for this project:
Automotive head production department supervisor.

The Power Line Supervision System is designed to detect and log the alarms signals generated by the various machines installed along the automatic line. The source, start date, duration and other information of each signal are recorded, in order to allow the shift maintenance operator to identify what is happening more quickly and any corrective actions to implement, provide the possibility of running retrospective reports and generating statistics on alarms and machine operating time/downtime.

Download a PDF file for this project:
Automatic assembly line process supervision

For a multinational in the graphite part production sector, various picking systems have been created with ABB anthropomorphic arm suitable for positioning (after receiving from a vibratory bowl) two formats of graphite washers, individualised, from 2 separate lines, in their pallets.

Download a PDF file for this project:
Design and production of automatic stations for loading and unloading graphite components onto/from presses with ABB anthropomorphic arm

The control system for the machine based on Siemens S7-300 PLC was designed and produced to make managing the machine’s operating cycles extremely dynamic and versatile through the creation of a system of parameter-based phases that, appropriately configured, allow the machine operating cycle to be modelled dynamically...

Download a PDF file for this project:
Revamping the control system for a tyre packing system
